LINGONG E6225H EXCAVATOR

General Information
Model: Lingong E6225H Excavator
Operating Weight: 22,500 kg
Engine Model: Weichai WP7.300 (6-cylinder, 7.1 L displacement) / Cummins QSL8.9
Emission Standard: China IV / EU Stage V
Net Power (ISO 9249): 221 kW (296.3 hp) @ 2,000 rpm
Bucket Capacity (Standard): 1.2 m³ (1.570 yd³)
Packing Dimension (L×W×H): 10,100×3,100×3,050 mm
Fuel Tank Capacity: 400 L
Hydraulic System Pressure: 35 MPa
Hydraulic Oil Tank Capacity: 160 L (42.27 gal)

Send Inquiry

Download

Product Description

Lingong E6225H 22.5-Ton Heavy-Duty Excavator – High-Power Efficiency: 221 kW Engine, 7m Dig Depth for Large-Scale Construction

The Lingong E6225H is a 22,500 kg (49,604 lbs) mid-large excavator engineered for heavy-duty large-scale construction, mining auxiliary, and infrastructure projects. With a 221 kW high-torque engine, 7m max digging depth, and robust digging forces, it balances raw power, operational efficiency, and durability—ideal for professional teams tackling high-load tasks in demanding environments.

Introduction

The Lingong E6225H integrates a Weichai WP7.300 (or optional Cummins) engine (221 kW, 1,200 N·m torque) with a 35 MPa high-pressure hydraulic system, delivering fast cycle times and strong digging performance. Its design features a reinforced heavy-duty boom/arm (thickness: 25 mm), intelligent load-sensing hydraulics, and a spacious low-noise cab (≤70 dB inside) with air-suspension seating for all-day comfort. Maintenance is streamlined with centralized service points and a 400 L large fuel tank for extended operation. It excels in 1.2 m³ bucket loading (cycle time ~7 seconds) and 7m deep trenching, making it a data-backed choice for high-productivity large projects.

LINGONG E6225H EXCAVATOR

Key Features

The product boasts several key features that set it apart:

1.High-Power Output: 221 kW engine + 1,200 N·m torque @ 1,400 rpm, delivering 125 kN arm digging force and 185 kN bucket digging force for ultra-heavy loads.

2.Intelligent Hydraulics: 35 MPa load-sensing system + dual-pump design, enabling 11 r/min swing speed and 5.8 m/s boom speed for fast cycle efficiency.

3.Durable Heavy-Duty Build: Reinforced boom/arm (high-strength steel, 25 mm thickness) + wear-resistant bucket (HB500 steel, 30 mm cutting edge) for 10,000+ hours service life.

4.Efficient Operation: Large-displacement main pump (2×170 cc) + optimized bucket design, boosting loading efficiency by 12% vs standard models.

5.Operator Comfort: Low-noise cab (≤70 dB) + air-suspension seat + 10-inch touchscreen display (real-time fuel/hydraulic data monitoring).

XCMG EXCAVATOR

Parameters

Parameter	Specification
Operating Weight	22,500 kg
Bucket Capacity	1.2 m³ (1.570 yd³)
Engine Model	Weichai WP7.300 / Cummins QSL8.9 (optional)
Engine Power	221 kW (296.3 hp) @ 2,000 rpm
Packing Length	10,100 mm
Packing Width	3,100 mm
Overall Height	3,050 mm

Working Scene

The Lingong E6225H excels in heavy-duty large-scale scenarios:

Construction & Infrastructure: Digging 7m deep foundations (matches 23 ft basement height), loading 1.2 m³ soil buckets (45 loads/hour), or bridge pier excavation.
Mining Auxiliary: Ore loading (1.2 m³ bucket, 40 cycles/hour), small quarry development, or mine site road construction.
Municipal Engineering: Trenching 1.0 m wide × 4.0 m deep for large pipelines (220 m/3 hours), road reconstruction (lifting 8,000 kg asphalt slabs).

product-1-1

Optional Accessories

All accessories come with clear performance specifications:

Attachments: Narrow trenching bucket (0.03 m³), grading bucket (0.035 m³), mini auger (100-200 mm diameter), rubber track pads.
Upgrades: Enclosed cab (with heater), LED work lights (800 lumens), quick coupler (for 2-minute attachment swaps).

product-1-1

Why Choose Us?

At Shenzhen HengChangSheng Machinery Equipment Co., Ltd, we offer more than just high-quality Lingong ER616H. Our commitment to customer satisfaction sets us apart:

Expertise: 10+ years of experience in supplying construction equipment for urban and rural use.
Quality Assurance: Each Lingong ER616H undergoes 200-hour load testing and 50-hour road simulation before delivery.
Competitive Pricing: Factory-direct quotes, saving 15% compared to distributors.
Excellent Support: 24/7 online guidance for operation and maintenance; on-site training for municipal teams.

product-1-1

Packaging & Shipping

We ensure secure packaging and efficient shipping of your product. Our team coordinates all logistics, from careful loading to timely delivery, whether you're a local or international buyer.

product-1-1

FAQ

Q: What’s the material handling efficiency?

A: With a 1.2 m³ bucket, it completes 65-75 cycles/hour, moving 78-90 m³ (102-117.7 yd³) of soil per hour (loose density: 1,600 kg/m³).

Q: How does fuel consumption vary with workload?

A: 15 L/h (50% load, grading), 16 L/h (70% load, digging), 17 L/h (90% load, lifting 10,000 kg).

Q: What’s the boom/arm service life?

A: Reinforced design ensures ≥10,000 working hours under standard operating conditions.

Q: Can it work at high altitudes?

A: It operates at up to 3,000 m altitude; power loss is ~8% (221 kW → 203.3 kW). An optional high-altitude kit reduces loss to ≤3%.
